OPT-VHK116/4.3-0.5X
Product Features
- High resolution optical design,compatible to line scan camera with 3.5um pixel.
- Relative distortion is below 0.005%.
- Broad spectrum range is from 400 to 900nm and achromatic design.
- Suitable for 63mm image circle and under of line and area scan camera.
Features
Resolution Comparison
Image taken by OPT-VHK 120/5.8-1.0X
Image taken by other lens
Specifications
Size
Dimensions (mm)
OPT-VHK98/3.9-0.23X
Applications
FPC locating and cutting
Capacitor surface inspection
Film hole inspection on mobile cover
Barcode reading on PCB
